GATE CSE 2020 Q30: Decoder inputs plus outputs for a byte-addressable 1 KB RAM

Digital Logic
1 mark
NAT
No negative marking

If there are $m$ input lines and $n$ output lines for a decoder that is used to uniquely address a byte addressable 1 KB RAM, then the minimum value of $m + n$ is ____.

Try it: numerical answer: type the value

Your answer

Numerical answer. No negative marking.

Show answer and explanation

Answer: 1034 (official GATE 2020 final answer key)

Concept used: An $m$ -to- $2^m$ decoder selects one of $2^m$ locations.

First step: 1 KB byte-addressable means 1024 locations, so $m = 10$ and $n = 2^{10}$ .

Full step-by-step solution

Detailed working, common mistakes and linked mock tests will be available with a free GATEiit account. Log-in is coming soon.
