GATE CSE 2022 Q29: Number of LR(0) items in goto on +

Consider the augmented grammar with $\{+, *, (, ), id\}$ as the set of terminals.

$\begin{aligned} S' &\to S \\ S &\to S + R \mid R \\ R &\to R * P \mid P \\ P &\to (S) \mid id \end{aligned}$

If $I_0$ is the set of two $LR(0)$ items $\{[S' \to S.], [S \to S. + R]\}$ , then $goto(closure(I_0), +)$ contains exactly __________ items.

Try it: numerical answer: type the value

Your answer

Numerical answer. No negative marking.

Show answer and explanation

Answer: 5 (official GATE 2022 final answer key)

Concept used: goto moves the dot over the symbol, then takes the closure of the resulting items.

First step: Only $[S \to S. + R]$ moves on $+$ , giving $[S \to S + .R]$ ; now add the closure items for $R$ and $P$ .

Detailed working, common mistakes and linked mock tests will be available with a free GATEiit account. Log-in is coming soon.
